CPC/CPCD Diesel Forklift — K Series (3.0–3.5 Ton)

SKU: DF-CPC-K

Low-chassis K-series diesel forklift for superior stability at 3.0–3.5 tons.

4 models available

Capacity range: 6,614 lbs (3.0 ton) — 7,716 lbs (3.5 ton)

Ships direct from factory via Rhenus Logistics. Typical transit: 4–6 weeks to North American facilities.

Product Description

The K series diesel forklift features a low-chassis design that lowers the center of gravity for superior stability when handling heavy, high loads. The streamlined hood and angled counterweight improve rear visibility. Built for demanding manufacturing environments where stability and precision placement are critical.

Specifications

Capacity6,614 / 7,716 lbs (3.0 / 3.5 ton)

Max Lift Height118.1 / 177.2 / 196.9 in (3000 / 4500 / 5000 mm)

Fork Length47.2 in (1200 mm)

Overall Width48.0–51.2 in (1220–1300 mm)

Turning Radius88.6–94.5 in (2250–2400 mm)

Travel Speed (Loaded)12.4 mph (20.0 km/h)

Lift Speed (Loaded)19.7 in/s (500 mm/s)

Gradeability (Loaded)22%

EngineYanmar 4TNV98T or Isuzu 4JG2 (diesel)

Engine Power45–55 kW

TransmissionTorque converter with powershift

Self Weight9,921–11,464 lbs (4,500–5,200 kg)

DesignLow-chassis, angled counterweight for rear visibility

Tilt6° forward / 12° backward

Models & Variants

Model	Capacity	Engine	Self Weight (lbs)
CPC30-K	6,614 lbs (3.0 ton)	Yanmar 4TNV98T	9921
CPCD30-K	6,614 lbs (3.0 ton)	Isuzu 4JG2	10141
CPC35-K	7,716 lbs (3.5 ton)	Yanmar 4TNV98T	11023
CPCD35-K	7,716 lbs (3.5 ton)	Isuzu 4JG2	11464

Warranty Information

3-year structural warranty, 2-year engine and transmission warranty. Xinchai/Yanmar engine with factory support.

3 yr

Structural Warranty

2 yr

Electrical / Motor

Quality Assurance

Every unit undergoes rigorous quality control before shipping from an ISO 9001-certified manufacturing facility.

ISO 9001 CertifiedCE Marked20+ Years ManufacturingGlobal Distribution
